Common Commands
Command Description Command Description
*CLS Clear status *RDT? Return output channel descriptions
*ESE <NRf> Standard event status enable *RST Reset
*ESE? Return standard event status enable *SAV <NRf> Saves an instrument state
*ESR? Return event status register *SRE <NRf> Set service request enable register
*IDN? Return instrument identification *SRE? Return service request enable register
*OPC Enable "operation complete" bit in ESR *STB? Return status byte
*OPC? Return a "1" when operation complete *TRG Trigger
*OPT? Return option number *TST? Performs self-test, then returns result
*RCL <NRf> Recalls a saved instrument state *WAI Pauses additional command processing
until all device commands are done
*RST Settings
These settings are set by the *RST (Reset) command
Calibration Function (Note 1) Measurement (continued)
CAL:STAT OFF SENS:SWE:OFFS:POIN 0
Current Function SENS:SWE:TINT 20.48E−6
[SOUR:]CURR 80 mA SENS:VOLT:RANG MAX
[SOUR:]CURR:MODE FIX SENS:WIND RECT
[SOUR:]CURR:PROT:STAT OFF Output Function
[SOUR:]CURR:RANG MAX OUTP OFF
[SOUR:]CURR:TRIG MIN OUTP:DEL:FALL 0
Digital Function OUTP:DEL:RISE 0
[SOUR:]DIG:OUTP:DATA 0 OUTP:PROT:COUP OFF
Display Function OUTP:PROT:DEL 0.02
DISP:VIEW METER1 OUTP:REL OFF
List Function (Note 1) Step Function
[SOUR:]LIST:COUN 1 [SOUR:]STEP:TOUT FALSE
[SOUR:]LIST:CURR MIN Trigger Function
[SOUR:]LIST:DWEL 0.001 INIT:CONT:TRAN OFF
[SOUR:]LIST:STEP AUTO TRIG:ACQ:SOUR BUS
[SOUR:]LIST:TERM:LAST OFF TRIG:TRAN:SOUR BUS
[SOUR:]LIST:TOUT:BOST OFF Voltage Function
[SOUR:]LIST:TOUT:EOST OFF [SOUR:]VOLT MIN
[SOUR:]LIST:VOLT MIN [SOUR:]VOLT:MODE FIX
Measurement Function [SOUR:]VOLT:PROT:LEV MAX
SENS:CURR:RANG MAX [SOUR:]VOLT:RANG MAX
SENS:FUNC “VOLT” [SOUR:]VOLT:SLEW MAX
SENS:SWE:POIN 1024 [SOUR:]VOLT:TRIG MIN
Note 1
The calibration state and all list settings are not saved by the *SAV command.
To Next Page
