Agilent Technologies X3500-64000 User Manual

Technical Information
Air Cooling Kit Installation
17
F i g u r e 2 0
TwisTorr 304 FS on board Controller User Manual / 87-901-028-01 (C)
171/178
1 Fix the fan to the suitable bracket by means of the furnished
screws;
2 Fix the bracket to the pump body between the pump and the
controller;
3 Connect the fan supply to the P4 connector of the controller.
Figure 19

Agilent Technologies X3500-64000 Specifications

General

Brand	Agilent Technologies
Model	X3500-64000
Category	Water Pump
Language	English
