Agilent Technologies X3500-64000

16
Instructions for Use
Installation
232/304 TwisTorr 304 FS User Manual / 87-901-027-01
Installation
CAUTION!
Do not remove the adhesive and protective cap before connecting the turbopump
to the system.
Figure 3
Install this device indoors only, and in any case do not use the pump
in an environment exposed to atmospheric agents (rain, ice, snow),
dust, aggressive gases, or in explosive environments or those with a
high fire risk.
During operation, the following environmental conditions must be
respected:
 maximum pressure: 2 bar above atmospheric pressure
 temperature: from +5 °C to +35 °C
 relative humidity: 0 – 90 % (non-condensing)
In the presence of magnetic fields the pump must be protected using
a ferromagnetic shield. See the appendix "Technical Information" for
detailed information.
The TwisTorr 304 FS pumps must be used in conjunction with one of
the suitable Agilent controller and they must be connected to a
primary pump (see "Technical Information").
Tab. 1
