Agilent Technologies X3500-64000

TwisTorr 304 FS User Manual
239/304
17
Technical Information
Description of the TwisTorr 304 FS 241
Pump Description 246
Technical Specification 248
TwisTorr 304 FS Outline 251
Interconnections 270
Earth (Ground) Connection 270
Connection C – Electrical 271
Soft Start 272
Inlet screen installation 273
Air Cooling Kit Installation 276
Water Cooling Kit Connection 278
Vent Accessories 281
TwisTorr 304 FS on board controller compatible Vent
Valve mod. 969-9834 281
TwisTorr 304 AG Rack Controller Compatible Vent Valve
mod. 969-9844 283
Vibration Isolator Installation 285
Purge Valve Installation 286
TwisTorr 304 FS On-board Controller Installation 288
Bottom Mounting 288
Side Mounting 289
Original Instructions
