Water Cooling Kit Connection
17
TwisTorr 304 FS User Manual / 87-901-027-01 279/304
CAUTION!
The items of the plastic model kit must be assembled as shown in the following
figure
Figure 42
The assembled kit must be screwed into the suitable holes of the
pump body with a recommended closing torque of 5 Nm.
The metallic model is assembled as shown in the figure.
Figure 43
