Introduction
4.4.5 Replace a station
Use this flowchart to replace a station.
Support Tool is needed to configure the system using this flowchart. Install Support Tool, and set for IPv6. For set up
information, refer to "IX Support Tool Setting Manual."
Can the Web server of the station to be replaced be accessed?
YES NO
1. Download the settings of the station to be
replaced.
“Settings File Backup (→page 153)”
1. Replace the station.
2. Replace the station. 2. Configure other stations in the same
manner using the newly installed station.
If the station settings were modified after being stored,
those changes will not be reflected.
“Settings File Backup (→page 153)”
The station is restarted and the IPv6 address is
automatically configured.
3. Upload the stored setting file to the newly
installed station.
“Settings File Backup (→page 153)”
The station is restarted and the IPv6 address is automatically
configured.
4. Search the station to install with Support
Tool for its IPv6 address.
3. Search the station to install with Support
Tool for its IPv6 address.
5. Replace the IPv6 address of the replaced
station that was registered in other stations
and software with the IPv6 address of the
newly installed station.
4. Replace the IPv6 address of the replaced
station that was registered in other stations
and software with the IPv6 address of the
newly installed station.
6. Finished. 5. Finished.

Aiphone IX SERIES Specifications

General

Series	IX Series
Communication	IP Network
Audio	Yes
Video Codec	H.264
Network	Ethernet
Video	Yes
Integration	Yes
Security	Encrypted Communication
Power	PoE (IEEE 802.3af)
Video Resolution	720p HD
Audio Codec	G.711
Mounting	Wall Mount
Relay Outputs	Yes
Inputs	Yes
Relative Humidity	90% or less, non-condensing
Audio Output	Speaker (Internal or External)
Audio Input	Built-in Microphone
Type	Video Intercom
