Aiphone IX SERIES Web Setting Manual

44
Startup and configuration
3. Connecting to a PC
Connect the station with a PC using a PoE compatible switch.
• Use CAT5e/6 straight cable to connect the devices through the LAN port.
• The station will start up with the default IP address of 192.168.1.160 and subnet mask of 255.255.255.0. Change
the PC IP address as necessary.
1 Door Station 4 PoE compatible switch
2 RJ45 5 PC
3 CAT5e/6 straight cable
22
1
3
4
22
3
5

Aiphone IX SERIES Specifications

General

Series	IX Series
Communication	IP Network
Audio	Yes
Video Codec	H.264
Network	Ethernet
Video	Yes
Integration	Yes
Security	Encrypted Communication
Power	PoE (IEEE 802.3af)
Video Resolution	720p HD
Audio Codec	G.711
Mounting	Wall Mount
Relay Outputs	Yes
Inputs	Yes
Relative Humidity	90% or less, non-condensing
Audio Output	Speaker (Internal or External)
Audio Input	Built-in Microphone
Type	Video Intercom
