Aiphone IX SERIES Web Setting Manual

74
Configuring the Station
2.5 Video (IX-DV and IX-DVF(-*) only)
2.5.1 Video Encoder 1
Configure settings for videos during calls between IX system stations, during communication, and during calls with
VoIP phones. The coding system will be H.264 / AVC.
■ Resolution
■ Frame Rate [fps]
Description Choose the resolution.
Settings • 320×240 (QVGA)
• 640×480 (VGA)
Default values 640×480 (VGA)
Description Choose the frame rate.
Settings 1, 2, 3, 5, 7.5, 10, 15, 20, 30 fps
When set to 7.5, 10, 15, 20, or 30 fps, the frame rate will drop to 5 fps once approximately 10
minutes have elapsed after an outgoing call is made.
Default values 15 fps
Note
• The frame rate may be lower than the set value depending on the video being sent, the number of recipient stations, and the
network environment.

Aiphone IX SERIES Specifications

General

Series	IX Series
Communication	IP Network
Audio	Yes
Video Codec	H.264
Network	Ethernet
Video	Yes
Integration	Yes
Security	Encrypted Communication
Power	PoE (IEEE 802.3af)
Video Resolution	720p HD
Audio Codec	G.711
Mounting	Wall Mount
Relay Outputs	Yes
Inputs	Yes
Relative Humidity	90% or less, non-condensing
Audio Output	Speaker (Internal or External)
Audio Input	Built-in Microphone
Type	Video Intercom
