Aiphone IX SERIES Web Setting Manual

75
Configuring the Station
■ Select Profile
■ I-picture interval♦
■ Bit rate [kbps]
■ RTP Start Port♦
■ RTP End Port♦
Description Configure the profile.
Settings • Baseline
• Main
• High
Default values Main
Description Configure the interval at which I-pictures are sent.
Settings 1 - 100
Default values 15
Description Set the bit rate.
Settings 32, 64, 128, 256, 384, 512, 768, 1024, 2048 kbps
Default values 1024 kbps
Note
• The bit rate may be lower than the set value depending on the video being sent, the number of recipient stations, and the
network environment.
Description Configure the range of ports communicating RTP.
The difference of (RTP Start Port) - (RTP End Port) should be 90 or greater.
If this is less than 90, a port outside the range may be used.
Settings 1 - 65534
Default values 30000
Description Configure the range of ports communicating RTP.
The difference of (RTP Start Port) - (RTP End Port) should be 90 or greater.
If this is less than 90, a port outside the range may be used.
Settings 1 - 65535
Default values 31000

Aiphone IX SERIES Specifications

General

Series	IX Series
Communication	IP Network
Audio	Yes
Video Codec	H.264
Network	Ethernet
Video	Yes
Integration	Yes
Security	Encrypted Communication
Power	PoE (IEEE 802.3af)
Video Resolution	720p HD
Audio Codec	G.711
Mounting	Wall Mount
Relay Outputs	Yes
Inputs	Yes
Relative Humidity	90% or less, non-condensing
Audio Output	Speaker (Internal or External)
Audio Input	Built-in Microphone
Type	Video Intercom
