Air Techniques, Inc.
Page 8
6.0 in.
(151.2 mm)
G
H
40.1 in.
(1019 mm)
46 in.
(1165 mm)
Horizontal Arm
length
G
H
(Head Turned in)
H (Head Turned out)
17.7 inches
(450 mm)
PN A6350-15
29.2 inches
(742.5 mm)
32.1 inches
(814.7 mm)
35.0 inches
(890 mm)
23.6 inches
(600 mm)
PN A6350-24
35.1 inches
(892.5 mm)
37 inches
(940 mm)
41 inches
(1040 mm)
35.4 inches
(900 mm)
PN A6350-33
48 inches
(1219.2 mm)
50 inches
(1270 mm)
53 inches
(1346 mm)
10.6 in.
(269 mm)
