Air Techniques PROVECTA HD - 3.2 Dimensions

Page 7
Air Techniques, Inc.
Product description
Horizontal Arm
length
A B C D E F
17.7 inches
(450 mm)
PN A6350-15
50.3 inches
(1278 mm)
56 inches
(1422 mm)
24.4 inches
(620 mm)
30.2 inches
(767 mm)
66.5 inches
(1689 mm)
8.6 inches
(220 mm)
23.6 inches
(600 mm)
PN A6350-24
56.25
inches
(1429 mm)
61.75
inches
(1568 mm)
31 inches
(787 mm)
36.5 inches
(927 mm)
71.75 inches
(1823 mm)
8.6 inches
(220 mm)
35.4 inches
(900 mm)
PN A6350-33
68.5 inches
(1740 mm)
73 inches
(1854 mm)
42 inches
(1068 mm)
48 inches
(1219 mm)
83.3 inches
(2118 mm)
8.6 inches
(220 mm)
C
D
46 in.
(1165 mm)
11.4 in.
(290 mm)
180
ο
280
ο
380
ο
46 in.
(1165 mm)
A
B
See Horizontal Arm
Length Below
3.2 Dimensions
E
F
21 in.
(524 mm)
DIMENTIONS 'A' THRU 'E' :
SINGLE POST WALL MOUNTING PLATE (P/N A6389) - ADD 0.5" (13mm)
16 CENTER TO CENTER WALL MOUNTING PLATE (P/N A6341) - ADD 1.0" (26mm)
