Air Techniques PROVECTA HD - 3.1 Technical data

Air Techniques, Inc.
Page 6
Product description
3.1 Technical data
Unit electrical data
Nominal voltage 100 to 240 V AC
Max. voltage fluctuation ±10%
Frequency 50/60 Hz
Power rating 500 W
Maximum power 750 VA
Classification
FDA 21 CFR Device Classification Class IIb
This X-ray system complies with US - FDA: 21 CFR Part 1010.2
21 CFR Part 1020.30/31
Degree of protection against ingress of water Ordinary
Medical products directive (93/42/EEC)
Manufacturer: VATECH Co., Ltd.
13, Samsung 1-ro 2-gil, Hwaseong-si, Gyeonggi-do, 18449, Korea
X-ray tube electrical data
X-ray Tube Type
Canon D-041SB (Stationary Anode Type)
Model
DG-10A05T3
Generator size and weight
5.5 x 6 x 3 in. (140 x 150 x 70 mm)
5.5 lbs. (2.5 kg)
Source to skin distance
8 in. (200 mm) 12 in. optional (300 mm)
Generator performance
0.5 kW
Nominal voltage (Accuracy)
50 to 70 kVp (±10%)
(Values below 60 kV are not in-
tended for human use in USA and Canada)
Nominal current (Accuracy)
4 to 7 mA (±20%)
X-ray tube cooling
Automatically controlled ≥ 122°F (50 °C)
(Air cooling: optional)
Inherent filtration
1.0 mm Al
Total filtration
Min. 2.0 mm Al
Focal spot size according to IEC 60336
0.4 mm
X-ray field collimation
∅ 2.4 in./1.2 x 1.6 in
2
(∅ 60 mm/30 x 40 mm
2)
Optional 0.8 x 1.2 in
2
(20 x 30 mm
2
)
Exposure time (Accuracy)
0.04 to 2 seconds (±5% or ±20 ms)
Anode material
Tungsten
Anode angle
12.5 degrees
Duty cycle
1:60 or greater
General technical data A6350-15 A6350-24 A6350-33
Arm length 17.7 in. (450 mm) 23.6 in. (600 mm) 35.4 in. (900 mm)
Storage height 46 in. (1165 mm)
Weight 55 lbs (24.9 kg) 56 lbs (25.4 kg) 59 lbs (26.7 kg)
Ambient conditions during operation during storage & transport
Temperature 50 to 95 °F (+10 to +35 °C) 14 to 140 °F (-10 to +60 °C)
Relative humidity 30 to 75% 10 to 75%
Air pressure 25 to 31 inHg (860 to 1060 hPa) 25 to 31 inHg (860 to 1060 hPa)
