Case Sizes
The Ecotel 5-15kW range has a total of two case sizes. The 5kW & 8kW units shall utilise the same case dimensions, as
shall the 12kW & 15kW units, which results in two case widths. The unit depth remains constant throughout the range.
The difference in capacities shall be dependent on component sizing within the unit case.
A
A
B B
ET05 / 08D-HX ET12 / 15D-HX
ET05/08D-HX ET12/15D-HX
Height (mm) (A)
2029 2178
Width (mm) (B)
910 1020
Depth (mm)
580 580
Cooling Capacity* (kW)
5-8 12-15
Number of Evaporator Fans
1/1 2/2
Number of Compressors
1/1 1/2
* At 30°C / 30% RH Air On, 35°C Ambient conditions
Temperature Range
Return Air Temperature +16°C to +30°C
Outdoor Temperature - Low -40°C to +40°C
Outdoor Temperature - Standard -20°C to +40°C
Outdoor Temperature - High Ambient -20°C to +45°C
Operating Limits
