AIREDALE ET05D - Et15 D

Ecotel™ Telecoms
64
Ecotel™ 5-15kW Technical Manual 9321381 V1.3.0 02_2018
Technical Data - 380V 60Hz
Mechanical Data
ET15D
1) The nominal DX capacity is based upon gross total cooling capacity at 30°C / 30%RH return air conditions, 35°C ambient temperature.
2) The nominal free cooling capacity is based upon a maximum airow and 10°C ΔT between ambient and return air.
Standard EC Fan. Upgraded EC Fan is available, see performance Graphs
ET15D-HX1F0-1 ET15D-HX1F1-1 ET15D-HX2F0-1 ET15D-HX2F1-1
Capacity - DX Cooling
Gross Total
(1) kW 14.97 14.97 14.76 14.76
Gross Sensible
(1) kW 14.97 14.97 14.76 14.76
EER
2.45 2.37 2.37 2.3
Capacity Steps
1 1 2 2
Capacity - Free Cooling
Gross Total
(2) kW 12.41 10.28 12.41 10.28
Max Airow
m³/s 1.03 0.85 1.03 0.85
Dimensions
W x D x H
mm 1020 x 580 x 2168
Weights
Machine
kg 339 339 370 369
Operating
kg 345 344 375 374
Construction
Material/Colour
Panels / Welded Frame: Galvanised Sheet Steel, Epoxy
Baked Powder Paint – Agate Grey (RAL 7038)
Evaporator
Ried Copper Tube/Turbulated Hydrophilic Coated Aluminium Fins
Quantity
1 1 1 1
Face Area
m² 0.348 0.348 0.348 0.348
Nominal Airow
m³/s 1.10 1.10 1.10 1.100
Discharge
Horizontal Horizontal Horizontal Horizontal
Condenser
Ried Copper Tube/Turbulated Hydrophilic Coated Aluminium Fins
Quantity
1 1 1 1
Face Area
m² 0.968 0.968 0.968 0.968
Nominal Airow
m³/s 1.76 1.76 1.76 1.76
Discharge
Vertical Vertical Vertical Vertical
Fan - Evaporator
EC DC EC DC
Quantity
2 2 2 2
Diameter
mm 310 310 310 310
Maximum Speed
rpm 2360 2020 2360 2020
Fan - Condenser
AC AC AC AC
Quantity
1 1 1 1
Diameter
mm 450 450 450 450
Maximum Speed
rpm 1600 1600 1600 1600
Compressor
Scroll Scroll Scroll Scroll
Quantity
1 1 2 2
Oil Charge Volume (Total)
l 1.57 1.57 2.12 2.12
Oil Type
PVE PVE PVE PVE
Refrigeration
Single Circuit Single Circuit Dual Circuit Dual Circuit
Refrigeration Control
EEV EEV EEV EEV
Refrigerant Type
R410A R410A R410A R410A
GWP
2088 2088 2088 2088
Charge (Total)
kg 5.16 5.16 2.69 , 2.68 2.69 , 2.68
Tonnes equivalent CO
2
tCO
2
10.77 10.77 5.62 , 5.60 5.62 , 5.60
Filtration
G4 G4 G4 G4
Quantity
1 1 1 1
Size W x D x H
mm 923 x 45 x 430 923 x 45 x 430 923 x 45 x 430 923 x 45 x 430
Optional Extras
Upgraded Fan - Evaporator
EC - EC -
Quantity
2 - 2 -
Diameter
mm 310 - 310 -
Maximum Speed
rpm 2640 - 2640 -
Upgraded Fan - Condenser
EC EC EC EC
Quantity
1 1 1 1
Diameter
mm 450 450 450 450
Maximum Speed
rpm 1500 1500 1500 1500
Filtration
M5 M5 M5 M5
Quantity
1 1 1 1
Size W x D x H
mm 923 x 45 x 430 923 x 45 x 430 923 x 45 x 430 923 x 45 x 430
Heating
kW 6.0 6.0 6.0 6.0
Technical
380V
