Technical Data - 380V 60Hz
Electrical Data
(1) Stated motor power values are based on absorbed electrical input power
(2) Electronic soft start gures are based on a 40% reduction in Compressor DOL starting current, nominal run amps at ARI condition
(3) Mechanical Cooling - ARI data is at nominal design conditions
(4) Mechanical Cooling - Max is worst case compressor loadings
ET15D
ET15D-HX1F0-1 ET15D-HX1F1-1 ET15D-HX2F0-1 ET15D-HX2F1-1
Electrical Supply Data
Mains Supply
V
380 / 3PH +
N / 60Hz
380 / 3PH +
N / 60Hz
380 / 3PH +
N / 60Hz
380 / 3PH +
N / 60Hz
Clients Backup Power Supply
V N/A 48VDC N/A 48VDC
Controls Circuit
V 24VAC 24VDC 24VAC 24VDC
Maximum Mains Incoming Cable Size
mm² 10 10 10 10
Mechanical Cooling - ARI (AC)
(3)
Nominal Run Amps
A 14.5 14.0 15.0 14.5
Maximum Start Amps
A 86 84.5 62 60.5
Recomended Mains Fuse
A 20 16 20 20
Mechanical Cooling - Max (AC)
(4)
Nominal Run Amps
A 16.3 15.8 17.4 16.9
Maximum Start Amps
A 86 84.5 63.2 61.7
Recomended Mains Fuse
A 20 20 20 20
Free Cooling mode (AC)
Nominal Run Amps
A 4.4 1 4.4 1
Clients -48VDC Backup Supply
Nominal Run Amps
A N/A 11.6 N/A 11.6
Recommended Mains Fuse
A N/A 16 N/A 16
Evaporator Fan - per Fan
Quantity
2 2 2 2
Motor Rating
kW 0.5 0.25 0.5 0.25
Full Load Amps
A 2.2 5.3 2.2 5.3
Locked Rotor Amps
A 2.2 5.3 2.2 5.3
Condenser Fan - per Fan
Quantity
1 1 1 1
Motor Rating
kW 0.82 0.82 0.82 0.82
Full Load Amps
A 3.5 3.5 3.5 3.5
Locked Rotor Amps
A 10.5 10.5 10.5 10.5
Compressor 1 - per Compressor
Motor Rating
kW 5.2 5.2 3.0 3.0
Full Load Amps
A 9.5 9.5 5.0 5.0
Locked Rotor Amps
A 81 81 52 52
Type of Start
Direct on Line Direct on Line Direct on Line Direct on Line
Compressor 2 - per Compressor
Motor Rating
kW N/A N/A 3.04 3.04
Full Load Amps
A N/A N/A 5 5
Locked Rotor Amps
A N/A N/A 52 52
Type of Start
N/A N/A Direct on Line Direct on Line
OPTIONAL EXTRAS
Heating
Power Rating
kW 5.4 5.4 5.4 5.4
Nominal Run Amps
A 8.2 8.2 8.2 8.2
No of Stages
1 1 1 1
No of Elements
6 6 6 6
Electronic Soft Start
(2)
Nominal Run Amps
A 14.5 14.0 15.0 14.5
Maximum Start Amps
A 53.6 52.1 41.2 39.7
Recommended Mains Fuse
A 20 16 20 20
