Refrigeration Components
Fixed Speed Scroll Compressor
The unit shall use a scroll type compressor. The larger capacity units shall be available in both single and dual circuit
congurations.
Evaporator Coil
A Round Tube Plate Fin heat exchanger shall be used as the evaporator. The aluminium ns shall have a hydrophilic
coating as standard.
Condenser Coil
As with the evaporator, the Round Tube Plate Fin heat exchanger shall be used as the coil type for the condenser.
The standard nish will be aluminium ns with the option for an epoxy coating to ensure a higher level of corrosion
resistance.
Features
System Conguration
ET05/08D-HX ET12/15D-HX
Refrigeration
Fixed Speed Scroll Compressor
● ●
Hydrophilic Coated Evaporator Coil
● ●
Condenser Coil
● ●
Epoxy Coated Condenser Coil
○ ○
Electronic Expansion Valves (EEV)
● ●
Refrigerant Leak Detection
○ ○
● Standard Features ○ Optional Features — Feature Not Available
Evaporator Coil Fixed Speed Scroll Compressor
