Technical Data - 220V 60Hz
Mechanical Data
ET15D
1) The nominal DX capacity is based upon gross total cooling capacity at 30°C / 30%RH return air conditions, 35°C ambient temperature.
2) The nominal free cooling capacity is based upon a maximum airow and 10°C ΔT between ambient and return air.
Standard EC Fan. Upgraded EC Fan is available, see performance Graphs
ET15D-HX1F0-2 ET15D-HX1F1-2
Capacity - DX Cooling
Gross Total
(1) kW 14.05 14.05
Gross Sensible
(1) kW 14.05 14.05
EER
2.54 2.46
Capacity Steps
1 1
Capacity - Free Cooling
Gross Total
(2) kW 12.41 10.28
Max Airow
m³/s 1.03 0.85
Dimensions
W x D x H
mm 1020 x 580 x 2168
Weights
Machine
kg 339 339
Operating
kg 344 344
Construction
Material/Colour
Panels / Welded Frame: Galvanised Sheet Steel, Epoxy
Baked Powder Paint – Agate Grey (RAL 7038)
Evaporator
Ried Copper Tube/Turbulated Hydrophilic Coated Aluminium Fins
Quantity
1 1
Face Area
m² 0.348 0.348
Nominal Airow
m³/s 1.10 1.10
Discharge
Horizontal Horizontal
Condenser
Ried Copper Tube/Turbulated Hydrophilic Coated Aluminium Fins
Quantity
1 1
Face Area
m² 0.968 0.968
Nominal Airow
m³/s 1.76 1.76
Discharge
Vertical Vertical
Fan - Evaporator
EC DC
Quantity
2 2
Diameter
mm 310 310
Maximum Speed
rpm 2360 2020
Fan - Condenser
AC AC
Quantity
1 1
Diameter
mm 450 450
Maximum Speed
rpm 1600 1600
Compressor
Scroll Scroll
Quantity
1 1
Oil Charge Volume (Total)
l 1.57 1.57
Oil Type
PVE PVE
Refrigeration
Single Circuit Single Circuit
Refrigeration Control
EEV EEV
Refrigerant Type
R410A R410A
GWP
2088 2088
Charge (Total)
kg 5.18 5.18
Tonnes equivalent CO
2
tCO
2
10.82 10.82
Filtration
G4 G4
Quantity
1 1
Size W x D x H
mm 923 x 45 x 430 923 x 45 x 430
Optional Extras
Upgraded Fan - Evaporator
EC -
Quantity
2 -
Diameter
mm 310 -
Maximum Speed
rpm 2640 -
Upgraded Fan - Condenser
EC EC
Quantity
1 1
Diameter
mm 450 450
Maximum Speed
rpm 1500 1500
Filtration
M5 M5
Quantity
1 1
Size W x D x H
mm 923 x 45 x 430 923 x 45 x 430
Heating
kW 6.0 6.0
