Technical Data - 230V 50Hz
Mechanical Data
ET05D
1) The nominal DX capacity is based upon gross total cooling capacity at 30°C / 30%RH return air conditions, 35°C ambient temperature.
2) The nominal free cooling capacity is based upon a maximum airow and 10°C ΔT between ambient and return air.
Standard EC Fan. Upgraded EC Fan is available, see performance Graphs
ET05D-HX1F0-7 ET05D-HX1F1-7
Capacity - DX Cooling
Gross Total
(1) kW 6.15 6.15
Gross Sensible
(1) kW 6.15 6.15
EER
2.91 2.89
Capacity Steps
1 1
Capacity - Free Cooling
Gross Total
(2) kW 5.25 6.59
Max Airow
m³/s 0.43 0.55
Dimensions
W x D x H
mm 910 x 580 x 2018
Weights
Machine
kg 278 279
Operating
kg 280 281
Construction
Material/Colour
Panels / Welded Frame: Galvanised Sheet Steel, Epoxy
Baked Powder Paint – Agate Grey (RAL 7038)
Evaporator
Ried Copper Tube/Turbulated Hydrophilic Coated Aluminium Fins
Quantity
1 1
Face Area
m² 0.304 0.304
Nominal Airow
m³/s 0.37 0.37
Discharge
Horizontal Horizontal
Condenser
Ried Copper Tube/Turbulated Hydrophilic Coated Aluminium Fins
Quantity
1 1
Face Area
m² 0.616 0.616
Nominal Airow
m³/s 1.66 1.66
Discharge
Vertical Vertical
Fan - Evaporator
EC DC
Quantity
1 1
Diameter
mm 310 355
Maximum Speed
rpm 1525 1760
Fan - Condenser
AC AC
Quantity
1 1
Diameter
mm 450 450
Maximum Speed
rpm 1400 1400
Compressor
Scroll Scroll
Quantity
1 1
Oil Charge Volume (Total)
l 0.74 0.74
Oil Type
POE POE
Refrigeration
Single Circuit Single Circuit
Refrigeration Control
EEV EEV
Refrigerant Type
R410A R410A
GWP
2088 2088
Charge (Total)
kg 2.36 2.36
Tonnes equivalent CO
2
tCO
2
4.93 4.93
Filtration
G4 G4
Quantity
1 1
Size W x D x H
mm 813 x 45 x 430 813 x 45 x 430
Optional Extras
Upgraded Fan - Evaporator
EC -
Quantity
1 -
Diameter
mm 310 -
Maximum Speed
rpm 2360 -
Upgraded Fan - Condenser
EC EC
Quantity
1 1
Diameter
mm 450 450
Maximum Speed
rpm 1500 1500
Filtration
M5 M5
Quantity
1 1
Size W x D x H
mm 813 x 45 x 430 813 x 45 x 430
Heating
kW 3.0 3.0
