AIREDALE ET05D - External

Ecotel™Telecoms
25
Ecotel™ 5-15kW Technical Manual 9321381 V1.3.0 02_2018
Features
System Conguration
ET05/08D-HX ET12/15D-HX
External
Integrated Mounting Flanges
● ●
Tamper Proof Fixings
● ●
Wooden Pallet Mounting
● ●
Ambient Weather Louvres
● ●
Fire Rated Damper
○ ○
Acoustic Plenum
○ ○
●
Standard Features ○ Optional Features — Feature Not Available
External
Integrated Mounting Flanges
The unit shall come with integrated mounting anges as standard. Fixings supplied by others.
Tamper Proof Fixings
The unit shall have vandal proof xings employed to all externally removable service panels.
Wooden Pallet Mounting
For specic markets units shall be shipped, mounted on wooden pallet and covered with polythene. The pallet shall be
mechanically xed to the unit for transportation only (Please contact Airedale for this option). Add 50mm to depth and
width, 160mm to height.
Ambient Weather Louvres
A weatherproof louvre shall be tted at the ambient air of the unit, to protect internal components. Complete with bird
mesh.
Fire Rated Damper
Optional curtain type re dampers shall be tted to supply and exhaust, with galvanised steel construction as standard.
Fire tested to BS EN 1366-2:1999 and classied to BS EN 13501-3:2005 + A1:2009.
