Ecotel™ 5-15kW Technical Manual 9321381 V1.3.0 02_2018
RxTx -
RxTx +
GND
RxTx -
RxTx +
GND
Panel Side
Customer Side
pLAN Termination
The plugged termination ensures that the connections are made simultaneously. Failure to attach the cables this way
may cause damage to the controller.
pLAN Termination
Installation
