Ecotel™Telecoms
29
Ecotel™ 5-15kW Technical Manual 9321381 V1.3.0 02_2018
Installation Data
Dimensions
ET12/15D-HX1F*-*
FAULT CODE
DISPLAY
(OPTIONAL)
PLENUM (OPTIONAL)
CUSTOMER INCOMING CABLES
(CONTROLS)
CUSTOMER INCOMING CABLES
(POWER)
INLET LOUVRE
EXHAUST LOUVRE
FRONT VIEW
SIDE VIEW
REAR VIEW
SUPPLY AIR (CABIN)
RETURN AIR (CABIN)
1020
699 237
1373
180
'A'
1237
580
'B'
'A'
A
DETAIL A
O 25
65
1101 47
89°
2168 201
2168
2178
275
1257 291
DIMENSION
AC CONDENSER
FAN 50Hz
AC CONDENSER
FAN 60 Hz
EC CONDENSER
FAN
'A' 2368 2368 2330 'B' 190 190 152
Installation
