Ecotel™ 5-15kW Technical Manual 9321381 V1.3.0 02_2018
Installation Data
Pipework Schematics
Dual Circuit
PT
PT
PT PT
TS TS
PSL PSL
PSH
PSH
5/16”
5/16”
5/16”
5/16”
5/16”
5/16”
5/16”
5/16”
Discharge Line
Liquid Line
Liquid Expansion
Line
Interlaced Evaporator
Coil
Suction Line
Interlaced Condenser
Coil
Circuit 2 - DX Circuit 1 - DX
TCETCE
PT
PT
PSH
PSL
5/16”
TCE
Sight Glass
Electronic Expansion Valve
Scroll Compressor
Filter Drier
Pressure Transducer
R410A 5/16” Schrader Valve
Low Pressure Switch
High Pressure Switch
Suction Line Temperature Sensor
Key: All Items
