AIREDALE ET05D - Page 43

Ecotel™Telecoms
43
Ecotel™ 5-15kW Technical Manual 9321381 V1.3.0 02_2018
Technical Data - 400V 50Hz
Electrical Data
ET05D
ET05D-HX1F0-0 ET05D-HX1F1-0
Electrical Supply Data
Mains Supply
V 400 / 3PH + N / 50Hz 400 / 3PH + N / 50Hz
Clients Backup Power Supply
V N/A 48VDC
Controls Circuit
V 24VAC 24VDC
Maximum Mains Incoming Cable Size
mm² 10 10
Mechanical Cooling - ARI (AC)
(3)
Nominal Run Amps
A 8.0 7.5
Maximum Start Amps
A 32.4 30.9
Recommended Mains Fuse
A 10 10
Mechanical Cooling - Max (AC)
(4)
Nominal Run Amps
A 9.0 8.5
Maximum Start Amps
A 32.4 30.9
Recomended Mains Fuse
A 16 10
Free Cooling mode (AC)
Nominal Run Amps
A 1.2 1
Clients -48VDC Backup Supply
Nominal Run Amps
A N/A 7.1
Recomended Mains Fuse
A N/A 10
Evaporator Fan - per Fan
Quantity
1 1
Motor Rating
(1) kW 0.15 0.29
Full Load Amps
A 1.2 6.1
Locked Rotor Amps
A 1.2 6.1
Condenser Fan - per Fan
Quantity
1 1
Motor Rating
(1) kW 0.6 0.6
Full Load Amps
A 2.9 2.9
Locked Rotor Amps
A 8.7 8.7
Compressor 1 - per Compressor
Motor Rating
(1) kW 2 2
Full Load Amps
A 3.6 3.6
Locked Rotor Amps
A 28 28
Type of Start
Direct on Line Direct on Line
Compressor 2 - per Compressor
Motor Rating
(1) kW N/A N/A
Full Load Amps
A N/A N/A
Locked Rotor Amps
A N/A N/A
Type of Start
N/A N/A
OPTIONAL EXTRAS
Heating
Power Rating
kW 3 3
Nominal Run Amps
A 4.3 4.3
No of Stages
1 1
No of Elements
3 3
Electronic Soft Start
(2)
Nominal Run Amps
A 8.0 7.5
Maximum Start Amps
A 21.2 19.7
Recommended Mains Fuse
A 10 10
Technical
400V
(1) Stated motor power values are based on absorbed electrical input power
(2) Electronic soft start gures are based on a 40% reduction in Compressor DOL starting current, nominal run amps at ARI condition
(3) Mechanical Cooling - ARI data is at nominal design conditions
(4) Mechanical Cooling - Max is worst case compressor loadings
