Ecotel™ 5-15kW Technical Manual 9321381 V1.3.0 02_2018
Technical Data - 400V 50Hz
Electrical Data
(1) Stated motor power values are based on absorbed electrical input power
(2) Electronic soft start gures are based on a 40% reduction in Compressor DOL starting current, nominal run amps at ARI condition
(3) Mechanical Cooling - ARI data is at nominal design conditions
(4) Mechanical Cooling - Max is worst case compressor loadings
ET12D
ET12D-HX1F0-0 ET12D-HX1F1-0 ET12D-HX2F0-0 ET12D-HX2F1-0
Electrical Supply Data
Mains Supply
V
400 / 3PH +
N / 50Hz
400 / 3PH +
N / 50Hz
400 / 3PH +
N / 50Hz
400 / 3PH +
N / 50Hz
Clients Backup Power Supply
V N/A 48VDC N/A 48VDC
Controls Circuit
V 24VAC 24VDC 24VAC 24VDC
Maximum Mains Incoming Cable Size
mm² 10 10 10 10
Mechanical Cooling - ARI (AC)
(3)
Nominal Run Amps
A 10.0 9.5 11.6 11.1
Maximum Start Amps
A 47.4 45.9 36.0 34.5
Recomended Mains Fuse
A 16 16 16 16
Mechanical Cooling - Max (AC)
(4)
Nominal Run Amps
A 11.7 11.2 13.6 13.1
Maximum Start Amps
A 47.4 45.9 37.0 35.5
Recommended Mains Fuse
A 16 16 16 16
Free Cooling mode (AC)
Nominal Run Amps
A 4.4 1 4.4 1
Clients -48VDC Backup Supply
Nominal Run Amps
A N/A 11.6 N/A 11.6
Recomended Mains Fuse
A N/A 16 N/A 16
Evaporator Fan - per Fan
Quantity
2 2 2 2
Motor Rating
(1) kW 0.5 0.25 0.5 0.25
Full Load Amps
A 2.2 5.3 2.2 5.3
Locked Rotor Amps
A 2.2 5.3 2.2 5.3
Condenser Fan - per Fan
Quantity
1 1 1 1
Motor Rating
(1) kW 0.6 0.6 0.6 0.6
Full Load Amps
A 2.9 2.9 2.9 2.9
Locked Rotor Amps
A 8.7 8.7 8.7 8.7
Compressor 1 - per Compressor
Motor Rating
(1) kW 3.31 3.31 2 2
Full Load Amps
A 5.6 5.6 3.6 3.6
Locked Rotor Amps
A 43 43 28 28
Type of Start
Direct on Line Direct on Line Direct on Line Direct on Line
Compressor 2 - per Compressor
Motor Rating
(1) kW N/A N/A 2 2
Full Load Amps
A N/A N/A 3.58 3.58
Locked Rotor Amps
A N/A N/A 28 28
Type of Start
N/A N/A Direct on Line Direct on Line
OPTIONAL EXTRAS
Heating
Power Rating
kW 6 6 6 6
Nominal Run Amps
A 8.7 8.7 8.7 8.7
No of Stages
1 1 1 1
No of Elements
6 6 6 6
Electronic Soft Start
(2)
Nominal Run Amps
A 10.0 9.5 11.6 11.1
Maximum Start Amps
A 30.2 28.7 24.8 23.3
Recommended Mains Fuse
A 16 16 16 16
