Technical Data - 230V 50Hz
Electrical Data
(1) Stated motor power values are based on absorbed electrical input power
(2) Electronic soft start gures are based on a 40% reduction in Compressor DOL starting current, nominal run amps at ARI condition
(3) Mechanical Cooling - ARI data is at nominal design conditions
(4) Mechanical Cooling - Max is worst case compressor loadings
ET08D
ET08D-HX1F0-7 ET08D-HX1F1-7
Electrical Supply Data
Mains Supply
V 230 / 1PH + N / 50Hz 230 / 1PH + N / 50Hz
Clients Backup Power Supply
V N/A 48VDC
Controls Circuit
V 24VAC 24VDC
Maximum Mains Incoming Cable Size
mm² 10 10
Mechanical Cooling - ARI (AC)
(3)
Nominal Run Amps
A 18.4 15.7
Maximum Start Amps
A 73.6 70.9
Recomended Mains Fuse
A 25 20
Mechanical Cooling - Max (AC)
(4)
Nominal Run Amps
A 22.9 20.2
Maximum Start Amps
A 73.6 70.9
Recommended Mains Fuse
A 32 25
Free Cooling mode (AC)
Nominal Run Amps
A 2.2 1
Clients -48VDC Backup Supply
Nominal Run Amps
A N/A 7.1
Recomended Mains Fuse
A N/A 10
Evaporator Fan - per Fan
Quantity
1 1
Motor Rating
(1) kW 0.5 0.29
Full Load Amps
A 2.2 6.1
Locked Rotor Amps
A 2.2 6.1
Condenser Fan - per Fan
Quantity
1 1
Motor Rating
(1) kW 0.6 0.6
Full Load Amps
A 2.9 2.9
Locked Rotor Amps
A 8.7 8.7
Compressor 1 - per Compressor
Motor Rating
(1) kW 2.55 2.55
Full Load Amps
A 11.8 11.8
Locked Rotor Amps
A 67 67
Type of Start
Direct on Line Direct on Line
Compressor 2 - per Compressor
Motor Rating
(1) kW N/A N/A
Full Load Amps
A N/A N/A
Locked Rotor Amps
A N/A N/A
Type of Start
N/A N/A
OPTIONAL EXTRAS
Heating
Power Rating
kW 3 3
Nominal Run Amps
A 13.0 13.0
No of Stages
1 1
No of Elements
3 3
Electronic Soft Start
(2)
Nominal Run Amps
A 18.4 15.7
Maximum Start Amps
A 46.8 44.1
Recommended Mains Fuse
A 25 20
