AIREDALE ET05D - Page 57

Ecotel™Telecoms
57
Ecotel™ 5-15kW Technical Manual 9321381 V1.3.0 02_2018
Technical Data - 230V 50Hz
Electrical Data
(1) Stated motor power values are based on absorbed electrical input power
(2) Electronic soft start gures are based on a 40% reduction in Compressor DOL starting current, nominal run amps at ARI condition
(3) Mechanical Cooling - ARI data is at nominal design conditions
(4) Mechanical Cooling - Max is worst case compressor loadings
ET12D
ET12D-HX1F0-7 ET12D-HX1F1-7 ET12D-HX2F0-7 ET11D-HX2F1-7
Electrical Supply Data
Mains Supply
V
230 / 1PH +
N / 50Hz
230 / 1PH +
N / 50Hz
230 / 1PH +
N / 50Hz
230 / 1PH +
N / 50Hz
Clients Backup Power Supply
V N/A 48VDC N/A 48VDC
Controls Circuit
V 24VAC 24VDC 24VAC 24VDC
Maximum Mains Incoming Cable Size
mm² 10 10 10 10
Mechanical Cooling - ARI (AC)
(3)
Nominal Run Amps
A 24.7 19.8 27.4 22.5
Maximum Start Amps
A 136.8 131.9 78.11 73.21
Recomended Mains Fuse
A 32 25 32 32
Mechanical Cooling - Max (AC)
(4)
Nominal Run Amps
A 29.7 24.8 34.0 29.1
Maximum Start Amps
A 136.8 131.9 81.38 76.48
Recommended Mains Fuse
A 40 32 40 40
Free Cooling mode (AC)
Nominal Run Amps
A 4.4 1 4.4 1
Clients -48VDC Backup Supply
Nominal Run Amps
A N/A 11.6 N/A 11.6
Recomended Mains Fuse
A N/A 16 N/A 16
Evaporator Fan - per Fan
Quantity
2 2 2 2
Motor Rating
(1) kW 0.5 0.25 0.5 0.25
Full Load Amps
A 2.2 5.3 2.2 5.3
Locked Rotor Amps
A 2.2 5.3 2.2 5.3
Condenser Fan - per Fan
Quantity
1 1 1 1
Motor Rating
(1) kW 0.6 0.6 0.6 0.6
Full Load Amps
A 2.9 2.9 2.9 2.9
Locked Rotor Amps
A 8.7 8.7 8.7 8.7
Compressor 1 - per Compressor
Motor Rating
(1) kW 3.45 3.45 2 2
Full Load Amps
A 15.9 15.9 9.3 9.3
Locked Rotor Amps
A 128 128 60 60
Type of Start
Direct on Line Direct on Line Direct on Line Direct on Line
Compressor 2 - per Compressor
Motor Rating
(1) kW N/A N/A 2 2
Full Load Amps
A N/A N/A 9.31 9.31
Locked Rotor Amps
A N/A N/A 60 60
Type of Start
N/A N/A Direct on Line Direct on Line
OPTIONAL EXTRAS
Heating
Power Rating
kW 6 6 6 6
Nominal Run Amps
A 26.1 26.1 26.1 26.1
No of Stages
1 1 1 1
No of Elements
6 6 6 6
Electronic Soft Start
(2)
Nominal Run Amps
A 24.7 19.8 27.4 22.5
Maximum Start Amps
A 85.6 80.7 54.11 49.21
Recommended Mains Fuse
A 32 25 32 32
Technical
230V
