Ecotel™Telecoms
59
Ecotel™ 5-15kW Technical Manual 9321381 V1.3.0 02_2018
Technical Data - 230V 50Hz
Electrical Data
(1) Stated motor power values are based on absorbed electrical input power
(2) Electronic soft start gures are based on a 40% reduction in Compressor DOL starting current, nominal run amps at ARI condition
(3) Mechanical Cooling - ARI data is at nominal design conditions
(4) Mechanical Cooling - Max is worst case compressor loadings
ET15D
ET15D-HX1F0-7 ET15D-HX1F1-7 ET15D-HX2F0-7 ET15D-HX2F1-7
Electrical Supply Data
Mains Supply
V
230 / 1PH +
N / 50Hz
230 / 1PH +
N / 50Hz
230 / 1PH +
N / 50Hz
230 / 1PH +
N / 50Hz
Clients Backup Power Supply
V N/A 48VDC N/A 48VDC
Controls Circuit
V 24VAC 24VDC 24VAC 24VDC
Maximum Mains Incoming Cable Size
mm² 10 10 35 35
Mechanical Cooling - ARI (AC)
(3)
Nominal Run Amps
A 29.6 24.7 30.7 25.8
Maximum Start Amps
A 124.8 119.9 86.76 81.86
Recomended Mains Fuse
A 40 32 40 32
Mechanical Cooling - Max (AC)
(4)
Nominal Run Amps
A 36.4 31.5 38.9 34.0
Maximum Start Amps
A 124.3 119.4 90.84 85.94
Recommended Mains Fuse
A 50 40 50 40
Free Cooling mode (AC)
Nominal Run Amps
A 4.4 1 4.4 1
Clients -48VDC Backup Supply
Nominal Run Amps
A N/A 11.6 N/A 11.6
Recomended Mains Fuse
A N/A 16 N/A 16
Evaporator Fan - per Fan
Quantity
2 2 2 2
Motor Rating
(1) kW 0.5 0.25 0.5 0.25
Full Load Amps
A 2.2 5.3 2.2 5.3
Locked Rotor Amps
A 2.2 5.3 2.2 5.3
Condenser Fan - per Fan
Quantity
1 1 1 1
Motor Rating
(1) kW 0.6 0.6 0.6 0.6
Full Load Amps
A 2.9 2.9 2.9 2.9
Locked Rotor Amps
A 8.7 8.7 8.7 8.7
Compressor 1 - per Compressor
Motor Rating
(1) kW 4.32 4.32 2.39 2.39
Full Load Amps
A 20.8 20.8 11.0 11.0
Locked Rotor Amps
A 116 116 67 67
Type of Start
Direct on Line Direct on Line Direct on Line Direct on Line
Compressor 2 - per Compressor
Motor Rating
(1) kW N/A N/A 2.39 2.39
Full Load Amps
A N/A N/A 10.96 10.96
Locked Rotor Amps
A N/A N/A 67 67
Type of Start
N/A N/A Direct on Line Direct on Line
OPTIONAL EXTRAS
Heating
Power Rating
kW 6 6 6 6
Nominal Run Amps
A 26.1 26.1 26.1 26.1
No of Stages
1 1 1 1
No of Elements
6 6 6 6
Electronic Soft Start
(2)
Nominal Run Amps
A 29.6 24.7 30.7 25.8
Maximum Start Amps
A 78.4 73.5 59.96 55.06
Recommended Mains Fuse
A 40 32 40 32
Technical
230V
