(1) Stated motor power values are based on absorbed electrical input power
(2) Electronic soft start gures are based on a 40% reduction in Compressor DOL starting current, nominal run amps at ARI condition
(3) Mechanical Cooling - ARI data is at nominal design conditions
(4) Mechanical Cooling - Max is worst case compressor loadings
Technical Data - 220V 60Hz
Electrical Data
ET08D
ET08D-HX1F0-2 ET08D-HX1F1-2
Electrical Supply Data
Mains Supply
V 220 / 3PH / 60Hz 220 / 3PH / 60Hz
Clients Backup Power Supply
V N/A 48VDC
Controls Circuit
V 24VAC 24VDC
Maximum Mains Incoming Cable Size
mm² 10 10
Mechanical Cooling - ARI (AC)
(3)
Nominal Run Amps
A 12.73 13.53
Maximum Start Amps
A 98.7 96
Recomended Mains Fuse
A 16 16
Mechanical Cooling - Max (AC)
(4)
Nominal Run Amps
A 14.9 15.7
Maximum Start Amps
A 98.7 96
Recomended Mains Fuse
A 20 20
Free Cooling mode (AC)
Nominal Run Amps
A 3.7 1
Clients -48VDC Backup Supply
Nominal Run Amps
A N/A 7.1
Recommended Mains Fuse
A N/A 10
Evaporator Fan - per Fan
Quantity
1 1
Motor Rating
(1) kW 0.5 0.29
Full Load Amps
A 2.2 6.1
Locked Rotor Amps
A 2.2 6.1
Condenser Fan - per Fan
Quantity
1 1
Motor Rating
(1) kW 0.82 0.82
Full Load Amps
A 3.5 3.5
Locked Rotor Amps
A 10.5 10.5
Compressor 1 - per Compressor
Motor Rating
(1) kW 2.8 2.8
Full Load Amps
A 9.0 9.0
Locked Rotor Amps
A 95 95
Type of Start
Direct on Line Direct on Line
Compressor 2 - per Compressor
Motor Rating
(1) kW N/A N/A
Full Load Amps
A N/A N/A
Locked Rotor Amps
A N/A N/A
Type of Start
N/A N/A
OPTIONAL EXTRAS
Heating
Power Rating
kW 3 3
Nominal Run Amps
A 7.9 7.9
No of Stages
1 1
No of Elements
3 3
Electronic Soft Start
(2)
Nominal Run Amps
A 12.7 13.5
Maximum Start Amps
A 60.7 58
Recommended Mains Fuse
A 16 16
