The Ecotel 5-15kW range shall offer the following:
Standard features:
● Fresh air free cooling ability with 100% mechanical backup and concurrent cooling stage
● R410A refrigerant
● Fixed speed scroll compressors
● Efcient EC evaporator fans
● Cost effective AC condenser fan
● Electronic expansion valve(s)
● G4 air ltration
● Spring return actuator (230V / -48VDC)
● 400V / 3PH+N / 50Hz
● High temperature cabin alarm
● Remote PGD1 display
● Return air temperature control
Optional features:
● Low and high ambient capability (-40°C / +45°C)
● DC emergency backup option
● 230V / 1PH + N / 50Hz
● 380V / 3PH + N / 60Hz
● 220V / 3PH / 60Hz
● Upgraded EC evaporator fans
● EC condenser fan
● Electric heating
● M5 air ltration
● Compressor soft start
● Filter change switch
● Refrigerant leak detection
● Power monitoring
● Alarm code display
Construction
There are 2 case sizes in the Ecotel Mk4 5-15kW product range; each case in the range shares a common design.
The cabinet shall be manufactured using a steel frame. Panels shall be removable to allow access to both the front
and sides of the unit. The galvanised sheet steel panels shall be coated with an epoxy baked powder paint to provide a
durable nish.
Standard unit colour shall be RAL 7038 (Agate Grey) or RAL 6014 (Yellow Olive).
The unit shall be lined internally with various thickness re resistant foam (BS 476) for thermal and acoustic insulation.
The insulation density shall not be less than 75kg/m³.
All unit panels are secured using tamper proof xings. A secondary internal panel, situated over the control panel, is
hinged and key lock secured. This panel provides additional protection and a weather hood once accessed.
A propriety rubberised door seal shall reduce sound breakout and eradicate air leakage. In-seal type foam based door
seals shall not be acceptable.
