(1) Values given for Cooling Only unit variants at 11°C evaporating and 46°C condensing.
(2) Stated motor power is based on maximum electrical power absorbed.
(3) Values are per compressor.
(4) Values may change based on additional selections (i.e. Heating).
(5) Values based on Fuse size., May change based on unit selections.
Technical - Direct Expansion
Electrical Data - Single Compressor (X1)
LIR6042U-X123 LIR6042U-X130
Standard Condenser Match - CR50 CR50
Unit Data Cooling only (1)
Nominal Run Amps A 20.1 21.2
Maximum Start Amps A 27.3 27.3
Recommended Mains Fuse Size (4) A 40 40
Max Mains Incoming Cable Size (5) mm² 16 16
Mains Supply 50Hz (-0) V 400V / 3PH + N / 50Hz
Mains Supply 60Hz (-1) V 380V / 3PH + N / 60Hz
Control Circuit VAC 24 24
Evaporator Fan - Motor - Per Fan
Motor Type EC EC
Quantity x Motor Size (2) kW 4 x 0.15 4 x 0.15
Full Load Amps A 1.2 1.2
Locked Rotor Amps A N/A N/A
Compressor 1 (3)
Motor Size kW 5.25 5.25
Nominal Run Amps A 18.8 18.8
Max Run Amps A 24.9 24.9
Type of Start Soft Start Soft Start
Compressor 2 (3)
Motor Size kW N/A N/A
Nominal Run Amps A N/A N/A
Locked Rotor Amps A N/A N/A
Type of Start N/A N/A
Standard Condenser Match – AC Motor Per Fan
Quantity x Motor Size (50Hz Supply) kW 2 x 0.6 2 x 0.6
Full Load Amps (50Hz Supply) A 2.6 2.6
Quantity x Motor Size (60Hz Supply) kW 2 x 0.5 2 x 0.5
Full Load Amps (60Hz Supply) A 2.2 2.2
OPTIONAL EXTRAS
Electric Heating
Stage of Reheat Variable Variable
Number of Elements 3 3
Rating (Total) kW 10.5 10.5
Current Per Phase (50Hz Supply) A 15.2 15.2
Current Per Phase (60Hz Supply) A 16.0 16.0
Standard Condenser Match - EC Motor-Per Fan
Mains Supply 50Hz (-0) V 230V / 1PH + N / 50Hz
Mains Supply 60Hz (-1) V 220V / 1PH + N / 60Hz
Quantity x Motor Size (50Hz Supply) kW 2 x 0.72 2 x 0.72
Full Load Amps (50Hz Supply) A 3.2 3.2
Quantity x Motor Size (60Hz Supply) kW 2 x 0.77 2 x 0.77
Full Load Amps (60Hz Supply) A 3.3 3.3
SCAF Condenser Match - Motor - Per Fan
Quantity x Motor Size (50Hz Supply) kW 2 x 1.4 2 x 1.4
Full Load Amps (50Hz Supply) A 6.0 6.0
Quantity x Motor Size (60Hz Supply) kW 2 x 1.75 2 x 1.75
Full Load Amps (60Hz Supply) A 7.8 7.8
