AIREDALE LogiCool InRak - Interconnecting Wiring

LogiCool InRak™
IT Cooling
60
InRak™ Technical Manual 7462807 V1.11.0_04_2016
Installation
Installation
Interconnecting Wiring
InRak
N1
 
Mains incoming supply 1
400V/3~/50Hz
380V/3~/60Hz
201
 
L1
202
 
L2
203
 
L3
PE
 
N2
 
Mains incoming supply 2
400V/3~/50Hz
380V/3~/60Hz
204
 
L1
205
 
L2
206
 
L3
PE
 
860
 
Supply Air Temperature Sensor 1
861
 
862
 
Supply Air Temperature Sensor 2
863
 
864
 
Supply Air Temperature Sensor 3
865
 
522
 
Remote On/Off
502
 
24 Vac
833
 
Outdoor Fan Speed Control 0 -10 Vdc
500
 
0 Vdc
560
 
NO Non-Critical Alarm Normally Open
561
 
Common Common
562
 
NC Non-Critical Alarm Normally Closed
563
 
NO Critical Alarm Normally Open
564
 
Common Common
565
 
NC Critical Alarm Normally Closed
CAUTION
The InRak does not support condenser sub fusing. To ensure full system uninterrupted power compatibility the external
condenser must have its own UPS.
