LogiCool InRak™
61
InRak™ Technical Manual 7462807 V1.11.0_04_2016
Installation
Installation
Interconnecting Wiring
InRak
Rx-Tx-
 
Network Connections (Incoming connection)
Rx+Tx+
 
GND
 
Rx-Tx-
 
Network Connections (Outgoing connection)
Rx+Tx+
 
GND
 
881
 
Wired BMS connection
(ModBUS, BACNet, LON,
RS485)
BMS Network Connections882
 
883
 
N/A
 
Ethernet BMS connection BMS Network Connections
