AIREDALE LogiCool InRak - Incoming Services - General

Bottom Entry - Direct Expansion
LogiCool InRak™
IT Cooling
56
InRak™ Technical Manual 7462807 V1.11.0_04_2016
Installation
Installation
Incoming Services
Top Entry - Direct Expansion
HOLE 'A' Ø50mm CONTROLS IN/OUT
HOLES 'B' Ø50mm MAINS POWER SUPPLY
HOLE 'C' Ø50mm
HOLE 'D' Ø50mm CONDENSATE DRAIN
HOLE 'E' Ø38mm 7/8" DISCHARGE LINE
HOLE 'F' Ø38mm 5/8" LIQUID LINE
D
B
C
A
E
F
B
HOLE 'B', 'E' AND 'F' TO BE SUPPLIED WITH GLAND PLATES FITTED.
ALL OTHER HOLES TO BE FITTED WITH BLIND GROMMETS.
VIEW FROM TOP
A
B C D
E
B
F
100
173
270
336
438
506
1040
62
164
248
75
600
HOLE 'A' Ø65mm CONTROLS IN/OUT
HOLES 'B'
Ø
50mm MAINS POWER SUPPLY
HOLE 'C' Ø50mm
HOLE 'D' Ø38mm CONDENSATE DRAIN
HOLE 'E' Ø76mm DISCHARGE LINE
HOLE 'F' Ø76mm LIQUID LINE
HOLES 'B','E' AND 'F' TO BE SUPPLIED WITH GLAND PLATES FITTED .
ALL OTHER HOLES TO BE FITTED WITH BLIND GROMMETS
A
E
F
B
C
D
B B
A
C
D
F
E
78.5
236.8
352.8
519.5
600
91
614.5
80.5
147.5
707
774
69.5
75.5
1040
VIEW FROM TOP
Cable and pipe work passing through oors / ceilings are required to be sealed by integral grommets to ensure efcient
unit operation.
