Technical - Direct Expansion
Electrical Data - Tandem Compressor (X2)
LIR6042U-X240-0 LIR6042U-X250-0
Standard Condenser Match - CR65 CR80
Unit Data Cooling only (1)
Nominal Run Amps A 27.9 29.4
Maximum Start Amps A 89.3 89.3
Recommended Mains Fuse Size (4) A 50 50
Max Mains Incoming Cable Size (5) mm² 16 16
Mains Supply 50Hz (-0) V 400V / 3PH + N / 50Hz
Mains Supply 60Hz (-1) V 380V / 3PH + N / 60Hz
Control Circuit VAC 24
Evaporator Fan - Motor - Per Fan
Motor Type EC EC
Quantity x Motor Size (2) kW 4 x 0.5 4 x 0.5
Full Load Amps A 2.2 2.2
Locked Rotor Amps A N/A N/A
Compressor 1 (3)
Motor Size kW 5.25 5.25
Nominal Run Amps A 18.8 18.8
Max Run Amps A 24.9 24.9
Type of Start Soft Start Soft Start
Compressor 2 (3)
Motor Size kW 4.28 4.28
Nominal Run Amps A 6.2 6.2
Locked Rotor Amps A 60.0 60.0
Type of Start Direct On Line Direct On Line
Standard Condenser Match – AC Motor
Per Fan
Quantity x Motor Size (50Hz Supply) kW 2 x 0.6 3 x 0.6
Full Load Amps (50Hz Supply) A 2.6 2.6
Quantity x Motor Size (60Hz Supply) kW 2 x 0.5 3 x 0.5
Full Load Amps (60Hz Supply) A 2.2 2.2
OPTIONAL EXTRAS
Electric Heating
Stage of Reheat Variable Variable
Number of Elements 3 3
Rating (Total) kW 10.5 10.5
Current Per Phase (50Hz Supply) A 15.2 15.2
Current Per Phase (60Hz Supply) A 16.0 16.0
Standard Condenser Match - EC Motor-
Per Fan
Mains Supply 50Hz (-0) V 230V / 1PH + N / 50Hz
Mains Supply 60Hz (-1) V 220V / 1PH + N / 60Hz
Quantity x Motor Size (50Hz Supply) kW 2 x 0.72 3 x 0.72
Full Load Amps (50Hz Supply) A 3.2 3.2
Quantity x Motor Size (60Hz Supply) kW 2 x 0.77 3 x 0.77
Full Load Amps (60Hz Supply) A 3.3 3.3
SCAF Condenser Match - Motor - Per
Fan
Quantity x Motor Size (50Hz Supply) kW 2 x 1.4 3 x 1.4
Full Load Amps (50Hz Supply) A 6.0 6.0
Quantity x Motor Size (60Hz Supply) kW 2 x 1.75 3 x 1.75
Full Load Amps (60Hz Supply) A 7.8 7.8
