• Formats and frame rates:
• (4K) 4096 x 2160p 23.98, 24, 25, 29.97, 50, 59.94
• (UltraHD) 3840 x 2160p 23.98, 24, 25, 29.97, 50, 59.94
• (2K) 2048 x 1080p 23.98, 24, 25, 29.97, 50, 59.94
• (HD) 1920 x 1080p 23.98, 24, 25, 29.97, 50, 59.94
• (HD) 1920 x 1080PsF 23.98, 24, 25, 29.97, 50, 59.94
• (HD) 1920 x 1080i 50, 59.94
• (HD) 1280 x 720p 50, 59.94
• (SD) 625i50
• (SD) 525i 59.94
• YCbCr, 4:2:2, 10-bit
Audio Input Digital
• 64-Channels via four 16-Channel audio disembedders (1 disembedder per SDI
input)
• 3G-SDI/HD/SD, SMPTE-272/299
• 20-bit SD, 24-bit 3G/HD, 48 kHz sample rate
• Drop/repeat sample rate conversion to match output reference
Audio Output Digital
• 64-Channels via four 16-Channel audio embedders
• 3G-SDI/HD/SD, SMPTE-272/299
• 20-bit SD, 24-bit 3G/HD, 48 kHz sample rate
• 64 x 64 mono audio matrix
Video Processing
• Proc amp controls
• Color corrector
• Legalizer
• Frame rate conversion (3:2, 1:2, 2:1)
• Delay 0-6 frames with H and V controls
• Closed Caption conversion (CEA-608/CEA-708)
• AFD input detection, down-convert control, and output pass through or
overwrite
• Freeze (manual or on input signal loss) to black or last good frame
• Matte generator for background ll
• Video test generator
• Nominal video delay
• 4K/UltraHD, 3 frames (LFR), 6 frames (HFR)
• HD/SD, 2 frames (LFR), 4 frames (HFR)
Format Conversion
Convert any supported input HD/SD format to any supported 4K/UltraHD/HD/SD
output format, as long as the input and output frame rates are of the same frame
rate family. These three families are:
• 59.94, 29.97, 23.98
• 50, 25
• 24
