FS3 Frame Synchronizer/Converter v1.1r1 91 www.aja.com
Scaling
• Zoom in and out
• Reposition
• Region of Interest
Up-Conversion
• 2K/HD/SD to 4K/UltraHD
• SD to 2K/HD
• Hardware 10-bit
• Zoom 14:9: results in a 4:3 image zoomed slightly to ll a 14:9 image with black
side bars
• Zoom Letterbox: results in image zoomed to ll full screen
• Zoom Wide: results in a combination of zoom and horizontal stretch to ll a
16:9 screen; this setting will introduce a small aspect ratio change
Down-Conversion
• HD/2K to SD
• Hardware 10-bit
• Anamorphic: fullscreen
• Letterbox: image is reduced with black top and bottom added to image area
with the aspect ratio preserved
• Crop: image is cropped to t new screen size
Aspect Ratio Conversion
• Letterbox: This transforms SD anamorphic material to a letterboxed image
• H Crop: Will produce a horizontally stretched eect on the image; transforms
anamorphic SD to full frame
• SD Pillarbox: Will produce an image in the center of the screen with black
borders on the left and right sides and an anamorphized image in the center
• V Crop: Will transform SD letterbox material to an anamorphic image
Audio Processing
• 64 x 64 mono audio matrix, route 1 to 1, 1 to many
• Independent controls for each channel
• Gain +18 to -18 dB in 0.5 dB steps
• Delay -16ms to 256 ms in 20.8 us steps
• Phase invert
• 5.1 or 7.1 to stereo mixdown with gain adjust
• Audio test generator
Timecode
• SDI RP188 via SDI BNC
Reference Input
• Blackburst or tri-level sync
• Looping, nonterminating
Network Interface
• 10/100/1000 Ethernet (RJ-45)
• Embedded web server for remote control
