FS3 Frame Synchronizer/Converter v1.1r1 92 www.aja.com
Machine Control
• RS-422, Sony 9-pin protocol (reserved for future use)
• GPI in/out, 15-pin D-connector (see "GPI Pinouts" on page 93)
Size (w x d x h)
• 17.5” x 16" x 1.75" 1RU (444.5mm x 406.5mm x 44.45mm)
Weight
• 7.9 lb (3.6 kg)
Power
• 100-240 VAC 50/60 Hz (Dual, redundant power supplies), 55W typical; 80W
max.
Environment
• Safe Operating Temperature: 0 to 40 degrees C (32 to 104 degrees F)
• Safe Storage Temperature (Power OFF): -40 to 60 degrees C (-40 to 140
degrees F)
• Operating Relative Humidity: 10-90% noncondensing
• Operating Altitude: <3,000 meters (<10,000 feet)
