Rear Panel Status LEDs
SDI In LED
This LED indicates the status of the SDI video input signal by color:
Off - No input or invalid input
Green - Lock to SD
Red - Lock to HD
Amber - Lock to 3G
HDMI In LED
This LED indicates the status of the HDMI video input signal by color:
Off - No input or invalid input
Green - Lock to SD
Red - Lock to HD
LAN LEDs
The LED on the right lights amber when there is an Ethernet link.
The LED on the left flashes green when data is being transferred.
