Chapter 5 – HELO Web Interface
Overview
Once installed and configured for operation, HELO can be controlled by
simply pressing the front panel Record and Stream buttons. To change HELO’s
configuration settings and for remote control of HELO, use HELO’s web interface.
Remote Control Overview
An optimized web server in HELO allows remote control and parameter setting
adjustments via a web browser client running on a network wired computer. The
network can be a closed local area network, a straight computer-to-HELO cable,
or even exposed through a firewall to a broadband WAN.
The LAN connection HELO uses is a standard RJ45 connector, but internally it’s
intelligent and communicates via standard “straight-through” CAT 5 Ethernet
cables or null-modem (cross-over) cables without any configuration or strapping
required.
NOTE: Safari is the preferred web browser for control on the Mac, and additionally
Chrome and Firefox on Windows. Other web browsers may work, but AJA cannot
guarantee consistent operation for all web browsers or web browser versions.
To connect to HELO, simply attach HELO to your network and enter HELO’s IP
address into the web browser. If authentication has been configured, you may
need to enter a password.
Web Browser via Ethernet
General Screen Description
All HELO web screens have certain areas and controls in common. Vertical and
horizontal scroll bars appear when information extends past the border of a
panel.
The round blue Up/Down arrow button on each panel and many status
parameters opens and closes that pane or set of parameters.
Menu Panel
On the left of each screen is a Menu panel listing all the available screens. Click
any of these links to jump to that screen.
Alarms Panel
Alarms are displayed in a panel on the left side of each screen. Clicking on the
arrow opens or closes this panel to show or hide the alarms. Hovering the mouse
over an alarm (red) or warning (yellow) may provide additional detail about the
condition.
