Recording Profile Copy From
You can copy all the settings from a different Recording Profile into the currently
selected profile.
1. Select the Recording Prole you want to change with the Recording Prole
drop-down menu.
2. Select the Recording Prole with the settings you want to save to the
currently selected prole with the Recording Prole Copy From drop-
down menu.
3. Click on the Recording Prole Copy From Apply button.
4. Click OK in the dialog box.
Recording Profile Settings
Recording Profile
Select the Recording Profile you want to use or edit from this drop-down menu.
Recording Profile Name
You can rename the Recording Profile with this parameter by typing in a name
and pressing Enter.
Frame Rate
Selects the encode frame rate relative to the input frame rate.
Full - The same frame rate as the incoming video will be recorded (factory
default).
Half - Every other frame will be recorded.
Quarter - Every fourth frame will be recorded.
Video Geometry
Selects whether the encoded video geometry is the same as the input or is set
manually.
Use Selected Input - Apply the incoming video aspect ratio to the recording
(factory default).
Manual - Allows adjustment of the size and aspect ratio of the recording. When
Manual is selected, the Lock Aspect Ratio control (On, Off) and the Width and
Height sliders become active.
Lock Aspect Ratio
Selects whether the encoded video's aspect ratio is the same as the input video,
or if the height and width can vary freely.
Off - The Width and Height sliders operate independently (factory default).
On - The Width and Height sliders are locked together. You can increase or
decrease the size of the recorded image, maintaining the aspect ratio.
Video Bit Rate
This slider adjusts the desired bit rate of the encoded video recording in Kbps
(kilobits per second) from a minimum of 100 to a maximum of 20,000 (factory
default). The slider control is color coded to indicate optimum settings. Staying
within the green range is optimum.
