AJA Ki Pro - Data-LAN and Data-FW Considerations; Encode Type; Play Media; Loop Play

50
Data-LAN and Data-FW Considerations
When the Ki Pro Media State, Data-LAN is used, only the web UI for control and
configuration of the Ki Pro may be used for data transfer. The web UI will present
"Upload+" and "Download+" buttons in the All Clips portion of the UI. If the Data -
LAN state is not active, these buttons do not appear in the web UI.
When the Ki Pro Media State, Data-FW is used, the Mac OS will mount the volume as a
disk. Because the Mac OS mounts the disk, the Mac OS should also be used to
unmount the disk from the operating system prior to switching the Media State back
to Record-Play. To unmount a volume in Mac OS, either drag the volume to the Trash
or use the eject icon in the Finder next to the volume. If this step is not followed, the
Mac OS may report that a disk has been improperly removed. If this happens, AJA
recommends mounting the disk to a Mac OS system in order to correct any directory
error that may have occurred due to the improper disk removal.
14.1 ENCODE TYPE
This parameter defines the Apple ProRes encoding method.
15.1 PLAY MEDIA
This parameter determines behavior during playback.
15.2 LOOP PLAY
This parameter turns looped playback on and off.
15.3 PLAYLIST
This parameter displays the name of the selected playlist.
14.1 ENCODE TYPE ProRes 422 (default)
ProRes 422HQ
ProRes 422LT
ProRes 422PX
Record media as Apple ProRes 422 files.
Record media as Apple ProRes 422 (HQ) files.
Record media as Apple ProRes 422 (LT) files.
Record media as Apple ProRes 422 (Proxy) files.
15.1 PLAY MEDIA One (default)
All
Playlist
Plays one clip and then stops playback
All/Playlist—Plays the current clip and then continues
playing the next clip on the Ki Pro media or the playlist.
Note that with this setting, Ki Pro will play clips back
regardless of format or framerate, but you may notice the
video monitor reset for format/framerate changes. If all
clips are the same format and framerate or conversion is
applied to the output for clips with the same Hz, then clips
play out smoothly one after another.
15.2 LOOP PLAY OFF (default)
ON
Play clip(s) and then stop playback when complete
Play clip(s) and then loop back and repeat playback
15.3 PLAYLIST variable The name of the selected playlist appears. If no playlist is
selected via the web UI controls, then no name appears.
The user cannot select or create playlists from the front
panel UI; these tasks are handled using the web UI.
