Location of the Controls
Record LED
CVBS Input
Audio Input Left
Audio Input Right
S-Video Input
Record
Stop
Aerial Input
Coaxial Output
Audio Output Right
CVBS Output
S-Video Output
RGB Component Video Output
Power Cable
Aerial Output (To TV)
SCART Socket 2
Standby
Play
Source
Disc Drawer
Eject
Standby LED
Audio Output Left
(Connection to
External Device)
SCART Socket 1
(Connection to TV)
