It is prohibited to drive so-called “wheelies” (taken-off anti-tippers from the wheelchair, e-fix wheels on the floor,
front wheels (castors) of the wheelchair hovering in the air). The Alber GmbH refuses to take over any liability for
accidents caused by this kind of driving.
1.7 Standard scope of delivery
• Two e-fix wheels
• Control unit including handrest
• Control unit bracket
• Battery pack
• Battery holder for the battery pack incl. motor supply lines
• Battery charger
• This operating manual
• Immobiliser key
The wheelchair must have special brackets to attach the e-fix wheels. If it does not, please contact your specialist dealer or an Alber
representative.
1.8 Optional accessories
• Intuitive attendant control
• Swivel arm for the control unit
• Opti-Box
• Speed-Stop/Speed limit switch
• Various joystick options
• Various battery packs
• Spoke cover
• External charger socket
• External On/Off switch
• Bumper bar for the control unit
We recommend using only original accessories supplied by Alber.
The e-fix is designed in such a way that it performs best when using Alber original accessories. Alber GmbH shall not be liable for damage
to the product or accidents (e.g. fires) caused by a malfunction of non-original accessories or spare parts. The warranty does not cover
repairs for damage caused by malfunction of non-original accessories. Alber GmbH will, however, carry out such repairs for you at a charge.
1.9 The main elements at a glance
(please fold out overview drawing in document cover)
Wheelchair and e-fix wheel Battery and battery holder
Bracket on wheelchair 1 Handle 25
e-fix wheel 2 Info button 26
Viewing panel on the e-fix wheel 3 Capacity indication 27
Releasing device 4 Fault indication 28
Coupling ring 5 Socket for connecting the control unit,
Wheelchair parking brake 6 the attendant control and the charger 29
Battery holder 7 Insertion aid on the battery holder 30
Battery pack 8
Control unit 9 Charger
Wheel socket 10 Charger 31
Stub axle 11 Charger mains plug 32
Torque plug 12 Charger plug 33
Wheel receiver 13 LED display 34
Control unit
Joystick 14
On/off button close range lighting 15
On/off button menu function 16
On/off button warning signal 17
Display 18
On/off button entire system 19
Immobiliser 20
Lighting (beneath the control unit) 21
Rotary switch for preselecting the speed 22
Plug with connection cable 23
Immobiliser key 24
!
