• For network configuration, any of the following must be implemented:
• In dynamic mode, a DHCP server must be configured
• In static mode, a free IP address must be available for the set
• A port with PoE must be available on a switch. If not available, a PoE injector must be used
4.4.2.1.2.2 Connecting the set
This section describes how to:
• Connect an 8082 My IC Phone set to the LAN (Local Area Network)
• Connect the external power adapter, if necessary
Note:
The external power adaptor is compatible with 8082 My IC Phone HW2, it is not compatible with version HW1.
Connecting an 8082 My IC Phone set to the LAN
To connect the set to the LAN:
• If you are using the 8082 Power Over Ethernet Injector Kit:
1. Plug an RJ45 cable between the data in port of the kit and the LAN
2. Plug an RJ45 cable between the data and power out port of the kit and the set LAN connector
3. Plug the kit to the mains
• If you are not using the 8082 Power Over Ethernet Injector Kit, plug an RJ45 cable between the set
LAN connector and a port of the switch
Connecting power supply
Note:
Only available for 8082 My IC Phone HW2
If you are not using a PoE switch or the 8082 Power Over Ethernet Injector Kit, connect the AC/DC
external adapter:
1. Plug the appropriate cable from the adapter into the set's power supply connector.
2. Connect the plug from the adapter to the mains power supply.
4.4.2.1.2.3 Initializing the sets
The following sections describe how to:
• Select the initialization type
• Initialize the 8082 My IC Phone set
Selecting the initialization type
The default initialization is Dynamic Alcatel.
To select the initialization type, refer to the following table.
table 4.1: Initialization type selection
If Then the required initiali-
zation type is
Further information
You use OXO Connect
DHCP server
Dynamic or Proprietary
Dynamic
• Refer to Configuring OXO Connect DHCP
server on page 79
You use another
DHCP server
Dynamic • Refer to Configuring an external DHCP
server for dynamic initialization on page 79
Chapter
4
Installation and Cabling
3EH21123USAA - Ed. 01 - April 2017 - Installation Manual 78/207
