C 90
3 / 6
Alcatel Vacuum Technology France --- IPUP A100 Instruction manual
Use of the serial link
LIST OF CONTROLS
ORDER
PARAMETER
RESPONSE ACTION
DLI XXX OK or ERR2
l Program the automatic transmission interval in minu-
tes: 1 to 255 sec.
DLR None OK l Start up the Data Logger (ATPI) for RS 232 only.
ECH ON or OFF OK or ERR2
l Return all characters received on the serial link in
the ECHON case.
HDR
<val>
see folio 6/6
OK or ERR3 l Change the response heading character.
IDN None V X.X l Send back the software version number
SET XXYZZZZ OK or ERR2
l Parameter setting
l Example : # 0 0 0 S E T X X Y Z Z Z Z
XX = 00 : reserved
01 : reserved
02 : reserved
03 : nitrogen flow
04 : reserved
05 : reserved
06 : purge flow prolonged
07 : full overhaul
08 : P out maintenance
09 : reserved
10 : exhaust Maintenance
11 : reserved
12 : reserved
13 : pressure alert threshold
14 : date setting : Day
15 : date setting : Month
16 : date setting : Year
17 : time setting : Hour
18 : time setting : Minute
19 : free
20 : setpoint (0) / ADP T° alarm (1)
21 : reserved
22 : reserved
Y = 0 : alert
1 : alarm
ZZZZ = threshold value (see page 5/6
)
SEP
<val>
seepage 5/6
OK or ERR3
l Used to change the separator character between
the two consecutive data items in a response.
SYS ON or OFF OK or ERR2
l Start up the pumping unit with SYSON and stop with
SYSOFF.
TPS XX
l Maintenance time
XX = 00 : running time
01 : full overhaul
02 : P out maintenence
03 : reserved
04 : exhaust Maintenance
05 : reserved
06 : reserved
