Alcatel Vacuum Technology France --- IPUP A100 Instruction manual
Use of the serial link
LIST OF CONTROLS (CONT’D)
ORDER
PARAMETER
RESPONSE ACTION
PUR ON or OFF OK or ERR2
l Start up the purge with PURON,
and stop with
PUROFF.
DEF XXY FAULT
l Display the 10 last Alerts or
Alarms
l Example : # 0 0 0 D E F X X Y
XX = 0 to 09
Y = 0 alarm
1 alert
l Transmission of a Data Logger frame
l Example :
#000 0010001000 0990 0 000 017 000 000 000 00 000000000000000000000 000
0/3 5/15 17/20 22/25 27/29 31/33 35/37 39/42 44/45 47/67 69/71
STA None
0 : header character
1---2---3: address
4 : separator character
5 : ADP status
6 : reserved
7 : purge status
8 : reserved
9 : water valve
10 : reserved
11 : reserved
12 : ADP water valve
13 : reserved
14 : reserved
15 : control in bit 3
and monitoring 0---1---2
16 : separator character
17---20 : pressure (mbar)
21 : separator character
22---25 : power (W)
26 : separator character
27---29 : ADP temperature (°C)
30 : separator character
31---33 : reserved
34 : separator character
35---37 : reserved
38 : separator character
39---42 : analog input (mV)
43 : separator character
44---45 : value hazard FC
46 : separator character
47 : pressure fault
48 : reserved
49 : reserved
50 : reserved
51 : reserved
52 : reserved
53 : frequency control
54 : reserved
55 : reserved
56 : motor temperature fault
57 : reserved
58 : reserved
59 : N2 purge fault
60 : maintenance fault
61 : ADP temperature fault
62 : N2 pressure fault
63 : reserved
64 : reserved
65 : reserved
66 : reserved
67 : reserved
68 : separator character
69---72 : N2 purging on second
73 : CR
