8.6 Torque Adjustment (See Fig. G)
(Screw driving force of your drill / driver)
The torque is adjusted by rotating the torque setting / collar (2).
The torque is greater when the torque setting / collar (2) is set on a
higher setting. The torque is less when the torque setting / collar (2)
is set on a lower setting.
Make the setting as follows:
1 - 4 for driving small screws
5 - 9 for driving screws into soft material
10 - 14 for driving screws into soft and hard material
15 - 19 for driving screws into hard wood
20 - 21 for driving larger screws
for heavy drilling
G
