There are two lights on the Ethernet jack:
Green light: On when Ethernet is working, flickers off to indicate
activity on the port.
Amber light: Off when successful 100Mbps link is established.
Typically on only briefly at power up.
Under normal conditions, the Amber light will turn on immediately
after the Ethernet cable is first connected. This indicates that PoE
power has been successfully applied. Once the device connects to the
network, it will switch to the Green light instead, which will typically
flicker indicating traffic on the network.
Door Control
Provides both normally open and normally closed relay contacts.
Serial Control
**Coming Soon**
Door Sensor (Dry Contact Input)
It can be configured as an auxiliary Call Button input. Additional
features coming soon.
