AlienDVR Megahero - System Setup and Connection Diagram

10
Smart Setup
Get more from your alienDVR with our Free CCTV tips at aliendvr.com
System Setup & Connection Diagram
VGA
NiteDevil Dome
CAM220
All-In-One 2MP IP
IP-CAM842
VoiceO
Audio Alarm Unit
VOX200
22” HDMI
Monitor
LCD822
alienPAD Keyboard
PTZ790
HDMI
Alarm
Outputs
RS232
RS485
USB Mouse
(Supplied)
IR Remote
(Supplied)
K&K Module
Timed Relay
Module REL008
KitVault
DVR Enclosure
CCT245
USB Backup
Trigger up to 9999 sounds.
Deter, Welcome, Warn &
Inform
BNC, VGA &
HDMI outputs
Up to 31 alienDVRs &
255 PTZ cameras can be
controlled from just one
alienPAD keyboard!
Use Kontrol & Kommand
modules to take control of
3rd party equipment easily
through the MegaHero.
Control:
For timed
relays use...
The KitVault keeps your Hero
locked, cool and secure.
Heating - ON 7am
- OFF 9am
Power - ON 6am
- OFF 5pm
Sirens
Lights
Gates
Cameras 1 - 16
(
Depending on model
)
Up to 18 IP Cameras
(
Depending
on model
)
KitVault
FREE
AlienVision
software with
every DVR
TIP
270
TIP
276
TIP
258
Remote Connect from laptops,
iPhones,iPads & Android devices.
More tips as aliendvr.com
Up to 18 IP Cameras
(
Depending
on model
Audio Add-on
CCT619
HD-TVI IR Eyeball
SEE810G
PIRs
CCT865
Record audio with
Lip Sync Quality!
The MegaHero has Alarm
Inputs for each channel.
Cameras 1 - 16
(
Depending
on model
)
