Removing the Logo Board
WARNING: Before working inside your computer, read the
safety information that shipped with your computer and
follow the steps in
Before Working Inside Your Computer.
After working inside your computer, follow the instructions
in After Working Inside Your Computer. For more safety best
practices, see the Regulatory Compliance home page at
dell.com/regulatory_compliance.
Prerequisites
1 Remove the stability foot.
2 Remove both the left and right side-panels. See “Removing the Side
Panels”.
3 Remove the memory fan.
Procedure
NOTE: Note the routing of all cables as you remove them so that you can
reroute them correctly after you replace the logo board.
1 Lay the chassis on the left side.
2 Disconnect all the cables from the connectors on the logo board.
3 Remove the screw that secure the logo board to the chassis.
113
